Crane BevMax 4 - Plunger Home (Red Light) Flow Chart

38
Check X Home =
Yellow light.
Visual check. Where is picker cup
located?
HOME NOT HOME
In position test. Press “0” key to cycle
plunger. Is Red LED
ON OFF
Cycle plunger multiple times to
ensure proper operation.
If Plunger is stuck in the
out or in position.
Refer to Delivery (Picker)
Cup Troubleshooting or
replace Cup Assembly.
Plunger Home =
Red light
ON OFF
