Crane BevMax 4 - Y Axis Home (Green Light) Flow Chart

40
Check, repair, or replace switch
or harness. Problem solved?
YES NO
Replace
control board.
Check All Home
LED’s are on.
Does motor run?
YES NO
Check, repair, replace
harness. Problem solved?
YES NO
Replace
control board.
Check belt
and pulley.
Is the Green
LED on?
YES NO
Do a Vend
Test with
Door Closed.
Is the display showing Encoder count with
a “1” at the end of the Y Axis code?
YES
N
O
###### 1 ###### 1
X axis Y axis
“1” showing = a switch or
ground wire issue.
“0” showing = a
mechanical
obstruction.
NO YES
Check & replace motor.
Problem solved?
YES NO
Y Axis Home =
Green light
ON OFF
Manually move cup to A9 and
pull top door switch out.
Press the “F” key. Picker Cup goes
to the home position?
YES NO
Manually activate the switch
and light cycles on and off.
YES NO
