70
MACHINE FRONT VIEW
ITEM PART DESCRIPTION
DN5800-4
DN5800-E4
DN3800-4
DN3800-E4
1 Door Assembly, Glass (does not include decals) 80010595 80010596
2 Gasket, Glass Door 80010297 80010298
3A Top Hinge Glass Door 65700036 Same
3B Carriage Bolt – ¼ - 20 x 1 1/4 80020243 Same
3C Hex Nut – ¼ - 20 80080157 Same
3D Washer, Flat 80070144 Same
3E Screw, Torx 8 X 5/8 (nib size TRX27) 48909108 Same
Screw, Fl. Torx Tap ¼-20 X ½
AP13100035
Same
Screw, Hex 8 X 5/8
80030468
Same
4A Top Hinge Service Door CR0002256 Same
4B Carriage Bolt, 1/4 –20 X 2.5” (also service door bottom hinge pin) 80020249 Same
4C Top Hinge Pin, Service Door CR0002219 Same
4D Lock Nut, Service Door Hinge Pin Bolt ¼ - 20 80030478 Same
4E Washer, Service Door Hinge Pin 900,701,19x.x1 Same
5A Door Switch Bracket – Single Switch 64700105 Same
Door Switch Bracket – Double Switch (electronic lock venders only) 64700104 Same
5B Power Interrupt Switch 80410059 Same
5C Lock Switch .1Amp (electronic lock venders only) 804,101,19x.x1 Same
6A Door Latch High Security, 2 Point Lock CR0010839 Same
6B Screw, Hex ¼ - 20 x 5/8 80030436 Same
7 Leg Assembly, welded in place 65700060 Same
8 Leg Leveler, 5/8 – 11 x 2 1/16 80050379 Same
9 Shipping Boards, Domestic CR0000969 Same
Shipping Boards, Export CR0004959 Same
10 Thermometer 80140155 Same
11 Wear Strip Door Decal 80387837 Same
12 Glass Door Bottom Hinge 65700035 Same
13 Bottom Panel Assembly CR0004713 CR0004585
14 Assembly Panel Slanted, with plastic evap box Refrig unit CR0007060 CR0007064
Assembly Panel Slanted with metal evap box Refrig unit CR0004787 CR0004853
15 Door Stop 64700045 Same
16 Wire Chase Assembly CR0004882 CR0004884
17 Ramp CR0002585 65707007
18 Warning Label, Ramp 80388543 Same
19 Evaporator Inlet Grill CR0002388 Same
20
Part numbers & descriptions are subject to change with out notice.
NA = Not applicable TBD = To be determined RB = Replaced by
