74
CABINET DETAIL SERVICE DOOR AREA
ITEM PART DESCRIPTION
DN5800-4/3800-4
DN5800-E4/3800-E4
Prior to s/n 9191BI
DN5800-4/3800-4
DN5800-E4/3800-E4
s/n 9191BI & higher
1 Coin Mech Housing Assembly 647,001,00x.x3 NA
2 Lower Coin Chute Assembly 80182342 Same
2A Lower Coin Chute Part of #2 Same
2B Lower Coin Chute Cover Part of #2 Same
3 Cash Box Clip 80181468 Same
4 Assembly, Lever Mech Arm Coin Return 647,003,20x.x3 NA
5 Assembly, Lever Button Rod 64700310 NA
6 Fuse 3 AMP/250V SloBlo for Motors (Control Board) 80480116 Same
7 Extension Spring ¼ x 1 ¾ x .029 MW 80170155 NA
8 Mech Door/Hinge Mech Assembly 64700400 CR0005660
9 Flat Mount Cable with adhesive 80480112 Same
10 Cash Box Cover 64700019 CR0007000
11 Coin Box Chute 647,000,18x.x3 CR0007266
12 Cash Box, metal 64700080 NA
Cash Box, plastic NA 4321228
13 Locking Cash Box Kit 432,011,50x.x4 Same
14 Upper Coin Chute 80182341 Same
15 Door Stop 64700045 Same
16 Roller Double Catch 80152201 NA
17 Lock Nut 8-32 80080155 Same
18
19
20 Coin Return Bracket Assy. NA CR0005542
21 Coin Paddle NA CR0005538
22 Coin Lever Spring NA CR0005873
23 Cash Box Blocker Bracket (attaches to bottom of service door) NA CR0007258
Part numbers & descriptions are subject to change with out notice.
NA = Not applicable TBD = To be determined RB = Replaced by
