76
XY MOTOR PICKER UNIT
ITEM PART DESCRIPTION
DN5800-4
DN5800-E4
DN3800-4
DN3800-E4
1 XY Delivery System CR0002183 CR00027472
2 Assembly Cover Y Belt CR0001797 Same
3 Y Motor Cover Top 80182329 Same
4 X Motor Cover Bottom 80182328 Same
5 X Bottom Belt Cover (Ramp) CR0002585 65707007
6 Harness, X Motor – bottom, not shown 80492825 Same
7 X Top Carriage Assembly (top of XY) CR0002121 Same
8 X Axis Mounting Assembly Top CR0002133 CR0002736
9 XY Extrusion (X track) 80120188 80120208
10 Harness, XY E Chain (Top horizontal) – not shown 80492826 80492894
11 Harness, Y E Chain (vertical) was 80492479 CR0013743 Same
12 XY Belt Idler Tensioning Assembly (top left) 64707970 Same
13 Motor XY System (Large D shaft) was 80450184 80450189 Same
14 Idler Pulley and Bracket Assembly 64708160 Same
15 X Top Idler Pulley Assembly 64708110 Same
16 Belt Clamp 80510003 Same
17 X Pulley Drive Assembly was 647,084,70x.x3 CR0006104 Same
18A Oilite Bushing no longer available NA NA
18B Tension Spring used in 647,084,70x.x3 only 801,701,71x.x1 Same
18C Pulley, 32 tooth “D” Drive 80530066 Same
19 X Motor Bracket Assembly was 647,084,60x.x3 CR0006104 Same
X Motor Bracket Cover was 64707148 NA Same
20 X Axis Belt (22’) 64707530 Same
21 X Bottom Carriage Assembly (bottom of XY) 64708240 Same
22 Assembly X Axis Drive, Bottom 64707930 CR0002741
23 Assembly Y Axis CR0002127 Same
24 Y Carriage Assembly 64708220 Same
25 Y Axis Belt (11.25’) 65700200 80510006
26 Screw Hex ¼ - 28 x .5 80020284 Same
Spacer, .257” 80530071 Same
Hex Nut, ¼ - 28 CR0004998 Same
27 Micro Switch with Straight Arm (X Home) 80410131 Same
28 Y Board 80492532 Same
29 Y Extrusion 80120207 Same
30 Pulley Roller 80530054 Same
31 XY Shipping Bracket 64707109 Same
32 Screw, Wing ¼ - 20 x 1 ¼ molded nylon (for shipping bracket) 80030529 Same
33 Belt Tensioner Spring (Y Belt only) 80140197 Same
34 Y Pulley Drive Assy. CR0005937 Same
Part numbers & descriptions are subject to change with out notice.
NA = Not applicable TBD = To be determined RB = Replaced by
