78
DELIVERY (PICKER) CUP ASSEMBLY
ITEM PART DESCRIPTION
DN5800-4
DN5800-E4
DN3800-4
DN3800-E4
1 Assembly Delivery (Picker) Cup Assembly w/ Sensor was 64708270 80182497 Same
2
Cup Base Board (Picker Cup Board with sensor) 3/26/08 & after
was 80492765
80492916 Same
3 Cup/Port Motor Assembly 80450161 Same
4 Cup Motor Cam 80120202 Same
5 Micro Switch with Bent Arm (Picker Home Switch) 80410137 Same
6 Micro Switch with Straight Arm (Cup Home Switch – Y) 80410135 Same
7 Micro Switch with Bent Arm (Picker Out Switch) 80410136 Same
8 Screw, Phil Pan 2 – 32 X 1/2 80030501 Same
9 Plunger Cup Bumper 80360123 Same
10 Base Cup Cover 80182289 Same
11 Delivery Cup Sleeve 80182258 Same
12 Delivery Cup Body 80182288 Same
13 Pin Cup Hinge 80120187 Same
14 Assembly Plunger 80520275 Same
15 Motor Cam Cover 64707035 Same
16 Return Spring, Plunger (Picker Cup) 80170167 Same
17 Cam Bearing 80530051 Same
18 Harness, Cup to E Chain 80492374 Same
19 Screw, 8 – 18 x ½ Pan Head, Machine 80030431 Same
20 Screw, #4 – 40 x 3/8 Machine w/ lock washer 80030503 Same
21 Cup Sensor Plate (3/26/08 & after) 64708090 Same
22 Flat Wire Clip 80181929 Same
23
24
Part numbers & descriptions are subject to change with out notice.
NA = Not applicable TBD = To be determined RB = Replaced by
