SERVICE DOOR (OUTSIDE) All BevMax 4
ITEM PART DESCRIPTION No Knock Out Knock Out Milled Knockout
1 Service Door Assembly, Gray (need to order item 23 separately) NA Same Same
Service Door Assembly, Black (need to order item 23 separately) NA Same Same
2 Weld Assembly Service Door CR0001802 Same Same
3 Assembly Bezel Top, Gray CR0004307 CR0005757 CR0005760
Assembly Bezel Top, Black CR0004306 CR0005758 CR0005759
4 Bezel Center, Gray NA 80182122 NA
Bezel Center, Black NA 80182123 NA
5 Bezel Bottom Electronic Lock, Gray (included in item 23) 80182118 NA NA
Bezel Bottom T Handle, Gray (included in item 23) 80182120 NA NA
Bezel Bottom Electronic Lock, Black (included in item 23) 80182119 NA NA
Bezel Bottom T Handle, Black (included in item 23) 80182121 NA NA
6 Coin Return Button Bracket was CR0002303 CR0005650 NA NA
7 Coin Return Button was 801,823,14x.x1 CR0007492 NA NA
8A Overlay, Keypad – Gray was 80388894 NA NA NA
8B Keypad Cover, Gray 80182462 NA NA
Keypad Cover, Black 80182461 NA NA
9 Keypad & Overlay, Membrane Switch Assembly with metal dome 80410142 NA NA
10 Coin & Keypad Bracket Assembly CR0001800 NA NA
11 Keypad security Bracket 64705037 NA NA
12 Assembly Port (with out LED’s) was 64705440 80182496 NA NA
13 Port Enclosure 80182400 NA NA
14 Port Cam 80182409 NA NA
15 Bracket and Motor Assembly (with notch) 64705400 NA NA
16 Assembly Inner Cup Port 80182097 NA NA
17 Vend Sensor Plate 64705360 NA NA
18 Port Discharge Pad 80360122 NA NA
19A Vend Sensor Board Assembly, Port CR0002851 NA NA
19B Port Sensor Cover/Housing CR0002214 NA NA
19C Port Sensor Harness 80492750 NA NA
19D Vend Sensor with Harness 80492749 NA NA
20 Motor Port Cover 80182068 NA NA
21 Port Handoff Slide 80182103 NA NA
22 Screw, Phil Pan 8 – 18 x5/8 (secures bezels to panel) 80030502 NA NA
23 Assembly Electronic Lock, Gray CR0004294 NA NA
Assembly T Handle, Gray CR0004287 NA NA
Assembly Electronic Lock, Black CR0004293 NA NA
Assembly T Handle, Black CR0004288 NA NA
24 Coin Insert Chute 80182355 NA NA
25 Extended Coin Return Cup Assembly (also see Service Door Inside) 80182429 NA NA
26 Port Circuit Board (top of port assy) 80492511 NA NA
27 Keypad Cable Clamp with adhesive was 80480112 CR0005752 NA NA
Part numbers & descriptions are subject to change with out notice. NA = Not applicable TBD = To be determined RB = Replaced by
