82
SERVICE DOOR (INSIDE)
ITEM PART DESCRIPTION
DN5800-4
DN5800-E4
DN3800-4
DN3800-E4
1 Display Lens, Blue (part of top bezel assy) NA NA
2 Screw, Nylon Circuit Board Support CR0002205 Same
3 Assembly Display (Noritake) 80492386 Same
4 Rod, Latch Bar 64705003 Same
5 Door Harness 804,928,36x.x1 Same
6 Extended Coin Return Cup Assembly 80182429 Same
7 Hex Nut, ½ - 20 80151802 Same
8A Door Security Plate (not shown) 64705041 Same
8B Validator Filler Plate (shown) 36005072 Same
9 Lock Bar Spacer Pin 80050412 Same
10 Lock Bar 64705002 Same
11 Enclosure, Port 80182400 Same
12 DEX Harness 80492827 Same
13 Hex Nut for DEX Harness 80080165 Same
14 Service Door Security Angle CR0001817 Same
15 Coin Insert Assembly CR0002043 Same
16 Compress Spring 80470154 Same
17 Keypad Cable Clamp with adhesive was 80480112 CR0005752 Same
18 Coin Return Button Bracket was CR0002303 CR0005650 Same
19 Coin & Keypad Bracket Assembly CR0001800 Same
20 Panel Retainer Clip (holds membrane switch.& overlay to bracket) CR0002204 Same
21 Coin Insert Chute 80182355 Same
22 Coin Return Button was 801,823,14x.x1 CR0007492 Same
23 Keypad & Overlay, Membrane Switch Assembly with metal dome 80410142 Same
24 Keypad Overlay, Gray was 80388894 NA NA
25 Extended Change Cup Security Bracket was 647,050,58x.x3 CR0005680 Same
26 T Handle Assembly 80152600 Same
27 T Handle Security Bracket 64705063 Same
28 Hex Washer #29-34, T Handle 90150308 Same
29 Door Switch Striker Plate was 64705057 & 64705038 CR0005680 Same
30 Port Circuit Board (top of port assy.) 80492511 Same
31 E Lock Assembly 80520274 Same
32 E Lock Harness was 80492341 80492665 Same
33 E Lock PCA Cover Bracket Left Side 64705008 Same
34 Seal, Rubber “D” Gasket NA NA
35 Vend Sensor Board Assembly, Port CR0002851 Same
36 Door Stop 64700075 Same
Part numbers & descriptions are subject to change with out notice.
NA = Not applicable TBD = To be determined RB = Replaced by
** Display Lens is sonic welded to top bezel and is not available as a separate item. See item 3 page 75.
