AC DISTRIBUTION BOX
ITEM PART DESCRIPTION
DN5800-4
DN3800-4
Domestic
DN5800-E4
DN3800-E4
Export
1 Assembly AC Distribution Box, BevMax 4 65707070 657,070,90x.x3
2 Transformer, 120V / 24V, 60 Hz, 8A Domestic 804,925,14x.x1 NA
Transformer, Export NA 80492868
3 Outlet, 15 Amp, Grounded W662 NA
Receptacle, Panel Mount IEC 320 NA 80491114
4 Power Inlet Plug 80491362 Same
5 Harness, AC Power In 80492843 Same
6 Harness, Power Distribution 80492842 Same
7 Harness, Main Power – GFCI Inline 65701080 NA
8 Choke 80492692 80492691
9 Relay – Fan, Compressor, and Light 80420026 Same
10 Rocker Switch 80491515 80410112
11 Harness, Relay 80492840 Same
12 Main Power Label was 80386085 80388747 Same
13 Label, AC Box Power Disconnect 80387694 Same
14 Defrost Control Harness 80492871 Same
15 Harness, Compressor Power AC Box (connects to 80492871011) 80492895 Same
16
17
18
19
20
21
22
23
24
25
26
27
Part numbers & descriptions are subject to change with out notice.
NA = Not applicable TBD = To be determined RB = Replaced by
