90
REFRIGERATION UNIT BevMax 4
(with Plastic Evap Box –9539-0032DJ and higher)
ITEM PART DESCRIPTION
DN5800-4/3800-4
Domestic
DN5800-E4/3800-E4
Export
1A Refrigeration Unit, 115V/60Hz Domestic Kit (Plastic Evap Box) 65701270 NA
Refrigeration Unit, 230V/50Hz Export Kit (plastic Evap Box) NA 65701290
2 Compressor Assy. FFU130HAX , 115V/60Hz Domestic 80250289 NA
2A Compressor, Domestic (Embracco 513200620) 80250288 NA
2B Compressor, Export NA CR0004162
3A Overload, 115V Domestic (EM# 513554617) 80240213 NA
4A Relay, 110V –Domestic (EM# 213516051) 80240216 NA
4B Relay, 220V –Export NA CR0004863
5 Cover, Electrical 80240214 CR0004172
6A Start Capacitor, 110V – Domestic (EM# 3252378) 80240218 NA
6B Start Capacitor, 250V/50Hz Export NA CR0004174
7 Start Capacitor, End Cap Bottom Hole 80240220 NA
8 Bracket, Capacitor 80240217 NA
9 Drain Pan, Condensate – with Wicks CR0002072 Same
10A Assembly Condenser Fan, Domestic CR0002309 NA
10B Assembly Condenser Fan , 220V, 16W, 10” Export NA CR0004747
11A Condenser Fan Motor, 9W Domestic was 80450193 80450187 NA
11B Condenser Fan Motor, Export 16W NA CR0004145
12 Silencer 80210052 Same
13 Fan Blade, Condenser 80130866 CR0004748
14 Speed Nut 80080199 Same
15 Condenser Coil CR0010358 Same
16 Dryer 80240129 Same
17 Grommet Compressor 90200057 Same
18 Evaporator Coil CR0004391 Same
19 Accumulator 80240046 Same
20 Encapsulated Temperature Sensor 80492821 Same
21 Assembly Evaporator Fan 115V Energy Star (5 blade) 80450154 NA
Assembly Evaporator Fan 230V/50Hz (5 blade) NA CR0004783
22 Evaporator Fan, 115V 80450151 NA
Evaporator Fan, EBM (5 blade) 220-230/50 includes harness NA CR0004180
23 Defrost Control CR0002421 Same
24 Evaporator Drain Pan Assy. NA Same
25 Condensate Drain P Trap CR0002026 Same
26 Deck Handle Clamp CR0002304 Same
27 Soaker 90580069 Same
28
Gasket Assembly – includes: A – CR0002551 Top Evaporator;
B – CR0002552 Right side Evaporator;
C – CR0005730 Lower Right side air gasket
CR0002615 Same
29 Refrigeration Deck Clamp CR0002203 Same
30 Grill CR0007259 Same
Part numbers & descriptions are subject to change with out notice. NA = Not applicable TBD = To be determined RB = Replaced by
