HARNESSES
ITEM PART DESCRIPTION FROM/TO
DN5800-4
DN5800-E4
DN3800-4
DN3800-E4
1 Harness, Electronic Lock 12 pin plug to E Lock board was 804,923,41x.x1
80492665 Same
(E-lock venders only) 2 connectors to door switch
1 jack in top of port
2 pin cap to top port lock board
2 Harness, Key Sensor Phone jack to top port lock board (TriTeq supplied only)
NA NA
3
Harness, Door Bundle 44”
long
Black & grey hrns 12 pin flat black plug to P2 of board, 4 pin white plug to
port motor, 7 pin flat white plug to port board.
Black hrns 10 pin flat white plug to PJ11 of board, 10 pin flat black plug to
key pad.
Black & black hrns 6 pin white plug to J16 or board, 6 pin white cap to mdb
mech, 6 pin white cap to mdb peripheral, 2 pin white plug to electronic lock if
used.
Grey hrns 7 pin flat black plug to P6 of board, 6 pin flat white plug to display.
80492836 Same
4 Harness, X Motor, 74” long 8 pin flat black at P15, 4 pin white plug to motor
80492825 Same
5
Relays Extension Harness,
23” long
10 pin flat black at P7 to 4 pin white plug at AC Distribution Box
80492828 Same
6
Harness, AC Distribution
Interior Power, 28” long
3 pin white plug at P1 to 9 pin white cap at AC Distribution Box, 2 pin white
plug at evaporator fan, 2 pin plug to 2 lamp ballast harness, 3 pin white plug
to 1 lamp ballast harness
80492819 Same
7
Harness, Evaporator, 80”
long
2 spade plugs to evaporator fan harness to 2 pin white plug from AC Box
Harness
80492848 Same
Harness, Evaporator Fan Connects to Fan
80492467 Same
8 Harness, Lighting 2 Lamp
9 pin white plug to ballast, 2 pin white cap to 2 pin white plug from AC
Distribution Box
80492844 Same
9 Harness, Top Light 1 Lamp
2 pin white cap from horizontal light to 2 pin white plug from lighting
harness
80492852 Same
10 Harness, Y Motor E Chain
10 pin Gray at J1 of Y board, 10 pin Gray to delivery cup harness
was 80492479
CR0013743 Same
11
Harness, Dual Door Switch,
E-Lock, 14” long
6 pin flat black at P10 to Double Door Switch
80492867 Same
Harness, Single Door Switch 6 pin flat black at P10 to Single Door Switch, 3 pin flat black to J3
80492823 Same
12 Encapsulated Temp Sensor 6 pin plug at J12 to Temp Sensor 87” long
80492821 Same
13
Harness, Port Cup Bottom –
Vend Sensor
4 pin plug to bottom of Port Cup
80492750 Same
14
Harness, Main Power 198”
long
Detachable GFCI Power Cord
65701080 Same
Cord, Power UK Detachable, 3 pin 78” long
80492566 Same
Note →
For more detachable power cords see page 96 item 18
15 Harness, AC Power In In AC Distribution Box 2 white caps, 2 red flag, 2 blue spade connectors
80492843 Same
16 Harness, DEX 36” long 4 pin flat black connector at J5
80492827 Same
17 Harness, Cup to E-Chain 10 pin Gray at J3 Picker Cup Board to Y E Chain (Black Ribbon Harness)
80492374 Same
18 Harness, Board to Y Motor 6 pin flat black at P1 Y Board to 6 pin white to Y Motor
80492421 Same
19
Harness, X/Y E Chain, 56”
long
14 pin flat black at P14 controller to 10 pin flat black at P6 Y Board, 5 pin
flat black at P8 controller to 4 pin flat black at P3 Y Board
80492826 80492926
20 Harness, Power Dist. 9 pin cap to relays & transformer
80492842 Same
21 Harness, Choke Output 9 pin plug to AC Dist. Box Choke
80492049 Same
22 Harness, Relay AC Box 4 pin cap to relay harness, compressor relay, fan relay, light relay
80492840 Same
23
Power Interrupt Sw. (Motor
By Pass) 21” long
2 pin white plug to P3
80492824 Same
24
Harness, Compressor
Extension 23” long
3 “U” shaped connectors from overload/relay to 3 pin white socket to item 28
80492849 Same
25
Harness, Compressor Power
Domestic
3 pin white plug to item 27 - 115” long
80492829 Same
Harness, Compressor Power
Export
3 pin white plug to item 27 - 115” long was 80492893
80492934 Same
26 Harness, Defrost Control 2 blue flag connectors to AC Box, 2 blue spade connectors to Defrost Control
80492871 Same
27
28
Part numbers & descriptions are subject to change with out notice.
NA = Not applicable TBD = To be determined RB = Replaced by
