Snack - Based Troubleshooting and Repair Guide
September, 2002 Page 37 of 54 1670065
A. Power Panel Assembly
Removal
CAUTION:
Prior to working on the
machine, be sure it is
unplugged from its power
source.
1. Remove one screw (figure 4).
Save the screw for later use.
2. Tilt the power panel out from the
machine and lift straight up (figure 5).
Figure 4
Figure 5
