Crane Snack Eenter I User Manual

Snack - Based Troubleshooting and Repair Guide
1670065 Page 48 of 54 September, 2002
CAUTION:
Observe proper ESD procedures. See "Preventing Circuit Board Damage
from Electrostatic Discharge" on page 1
1. Install the emitter circuit board and paper insulator using 5 Phillips head screws.
2. Hook the slot in the emitter cover over the tab on the emitter bracket. Secure the emitter
cover to the door with 1 hex head screw.
3. Install the receiver bracket and secure with 2 hex head screws (one into the delivery pan;
one into the door).
CAUTION:
Observe proper ESD procedures. See "Preventing Circuit Board Damage
from Electrostatic Discharge" on page 1
4. Install the receiver circuit board and paper insulator using 5 Phillips head screws.
5. Hook the slot in the receiver cover over the tab on the emitter bracket. Secure the emitter
cover to the delivery pan with 1 lock nut.
6. Route the SureVend™ harnesses and connect to the circuit boards. Secure harnesses with
the harness clips.
