Product Manual — Doc. 7696D DGE-100 and DM-DGE-200-C • 7
DM-DGE-200-C Features
The Crestron® DM-DGE-200-C digital graphics engine transforms an HD or Ultra HD touch
screen display into an advanced Crestron controller. The DM-DGE-200-C features Smart
Graphics® technology that may be used to create a custom graphical environment for controlling
audio, video, lighting, shades, HVAC, security, and other amenities. The DM-DGE-200-Ccan also
be used for functions with dual-window video display, annotation, audio feedback, and web
browsing. Its low-profile, surface-mountable design allows for a discreet installation behind a
flat-panel display, under a table, or inside a lectern or equipment rack.
The DM-DGE-200-C features a 4K UHD capable HDMI® output for connecting to a display
device, and includes a USB HID port for touch, mouse, or keyboard input. Additional control ports
are provided for controlling the display device and other equipment.
1,2
The HDMI input allows an
AirMedia® wireless presentation gateway or other high-definition video source to be connected
and displayed on-screen. The DM 8G+® input supports 4K UHD and DCI 4K sources connected at
a DM® transmitter or switcher.
3
Additionally, H.264 streaming video signals can be received over
a high-speed Ethernet connection, and Ethernet provides an interface to a Crestron control
system.
4
NOTE:An Ethernet connection is required for touch screen and OSM control applications.
