Product Manual — Doc. 7696D DGE-100 and DM-DGE-200-C • 63
5. Select Send EDIDto load the CEDIDfile to the DGE. The upload progress is shown in the
dialog box.
6. Once the DGEhas completed the upload, select OK.
Input Signal (DMIn)
Expand the Input Signal accordion to view the status of the input signal connected to the
DMinput (if one is present).
l
Sync Detected:Reports whether the DMinput signal is synced to the DGE.
l
Resolution:The resolution of theDMinput signal.
l
Source HDCP:Reports whether HDCPis active or inactive on the DM input signal.
Select + More Details to display an expanded section that shows additional information about
the DMinput signal. If + More Details is selected, select - Less Details to collapse the section.
HDMIOutput
Select HDMI OUTPUTfrom the navigation menu to display collapsible accordions for configuring
the HDMIoutput settings.
Select an accordion name to expand the section. If the section is expanded, select the accordion
name again to collapse it.
Each selection is described in the sections that follow.
