Crestron Mercury CCS-UC-1 User Manual

10 • CCS-UC-1: Crestron Mercury Tabletop Conference System Product Manual – DOC. 7844M
2. The CCS-UC-1 has two network adapters, Adapter 1 and Adapter 2. Adapter 1 is
the name assigned to the LAN port and
Adapter 2 is the name assigned to the
AUX port. Each network adapter can be set to have their IP address, subnet
mask, default gateway, and DNS servers set manually, or obtain the settings
from a DHCP server. Choose one of the following options for each network
adapter.
NOTE: On the CCS-UC-1-X, Adapter 2 configures the TX OUT port. The TX OUT
port can function as a direct HDBaseT output connection to an HDBaseT receiver
or as an auxiliary LAN connection. If the TX OUT port is connected to an HDBaseT
receiver, do not change any of the settings. If the TX OUT port is to be used as an
auxiliary LAN connection, configure the port as required.
− Set DHCP to Enabled to use a DHCP server to provide the IP address, subnet
mask, default gateway, and DNS server.
− Set DHCP to Disabled to manually enter the Ethernet parameters. When set
to
Disabled, the IP address, subnet mask, default gateway, and DNS servers
must be manually entered.
3. Click Save Changes when done or Revert to return to the previous setting.
NOTE: Any changes made to the network settings will require the device to reboot.

Crestron Mercury CCS-UC-1 Specifications

General

Brand	Crestron
Model	Mercury CCS-UC-1
Category	Conference System
Language	English
