CROSSJET AC 92-18 - Technical Parameters

3. TECHNICAL PARAMETERS
type AC92-18(20) type AC92-234x4
Weight 298 kg 345 kg
Dimensions (LxWxH) 2,090x990x985mm 2,230x1,047x990
Engine
Briggs & Stratton Vanguard 20HP
V-Twin (BS20)
Briggs & Stratton Vanguard 18HP
V-Twin (BS18)
Briggs & Stratton Vanguard 23HP
V-Twin (BS23)
Engine type
4-cycle OHV, gasoline engine with vertical shaft
Engine output
20HP / 14.72 (BS20)
18HP / 13.25 (BS18)
23HP / 16.93 (BS23)
Max. engine revolutions 3,000 rpm
Fuel Led-free gasoline Natural 95
Gas tank volume 12 l
Transmission
transmission Tuff-Torq K62 with
continuous gear-ratio (speed) change
and with manually applied differential
lock
transmission Tuff-Torq K664 with
continuous gear-ratio (speed) change
and with manually applied differential
lock and front wheel drive KXH10N
Speed: forward 0-8.5 km/h 0-9 km/h
Speed: reverse 0-4.5 km/h 0-5 km/h
Cutting width 92 cm, two changeable knifes
Cutting height
50-60-75-90 mm,
+ mulching position
50-60-70-80-100 mm, transport position
Mowing clutch electromagnetic
Driving break mechanical with drums
Parking break mechanical
Tire dimension: front
14x4.50-6
16x6.5-8
Tire dimension: rear 18x9.50-8 20x10.0-8
Tire pressure: front 150 kPa 150 kPa
Tire pressures: rear 80kPa 80kPa
wheel span: front 820 mm 814 mm
wheel base: rear 750 mm 790 mm
Wheel base 1,450 mm 1,560 mm
Maximum pressure in the
hydraulic system
--- 20 MPa
Total value of vibration acceleration ( m.s
-2
)
in accordance with EN 836+A1/A2, appendix G
Engine Revolution
±100 (min-1)
Declared noise level at the driver seat L
pAd
(dB) in accordance with EN ISO
836+A1/A2, appendix H and EN ISO
11201
seat steering wheel floor
BS18 3000 88,4 0,23 2,38 1,61
total av vibration
in accordance with EN 1032
vibrations transmitted to ah
v
arm
in accordance with EN 1033
BS20 3000 90 0.56 < 2.5
BS23 3000 91 1,5 < 2.5
37
