Page 13
VIEW MEMORY MODE
This PW version 6.20 and up alarm panel has an event memory which stores the most recent events (up to 255
events) including all alarm events, all system events such as mains failure etc as well as settings. This event
memory is displayed via the standard keypad with the most recent event shown first and subsequent events
following in descending order from newest to oldest.
The "MEMORY" light will flash on and off when there is a new event in memory which has not been viewed. To
stop the "MEMORY" light flashing, simply press the MEMORY button and the event memory will be flashed back to
you with the most recent event shown first. Each event is separated by a beep tone.
Current System Alarms
When viewing the memory event buffer at the keypad by pressing the “MEMORY” button, the first thing that will
always be displayed is the Current System Alarms that are still present. The Current System Alarms are indicated
by the Memory/Mains & Battery LEDS being on plus a zone LED from 1-8 to indicate the system alarm/s present. If
no Zone LED’s are on at this time, it means that there are no current system alarms. If a zone LED or LED’s are On
then this indicates system alarms that have not yet cleared. The zone LED’s 1-8 are pre-defined as to what system
alarm they will display. These system alarm indications are shown in the table below. Following the display of
current system alarms the panel will then sequence through the 255 historical memory events starting at the most
recent event. The second table shows the alarm events that can be displayed in memory mode and what indicators
are used to show them.
HISTORICAL EVENT DISPLAY CHART
EVENT DEVICE INDICATOR STATUS
ACTIVATION
Zones 1-16 LED's 1-16 On Steady
EXCLUDE
Zones 1-16 Bypass
LED's 1-16
On Steady
On Steady
DETECTOR TAMPER
(SHORT CIRCUIT)
Zones 1-8 TAMPER
LED's 1-8
Flashing
On Steady
DETECTOR TAMPER
(OPEN CIRCUIT)
Zones 9-16 TAMPER
LED's 9-16
Flashing
On Steady
CABINET TAMPER Cabinet or Satellite Siren TAMPER Flashing
WRONG CODE ALARM
Code Tamper at
Keypad #
TAMPER
LED’s 1-8
On Steady
On Steady
CROW KEYPAD TAMPER SWITCH
ACTIVATED
Keypad Tamper Alarm at
Keypad #
TAMPER
LED’s 1-8
On Steady
On Steady
LOW BATTERY
Controller Battery BATTERY Flashing
MAINS FAILURE Controller Mains Supply MAINS Flashing
FUSE FAILURE (F1 or F2)
Controller on-board fuses MAINS Flashing
LED # 1
Battery Low
LED # 5
Radio Pendant Battery Low
LED # 2 Mains or 12V Fuse Failure LED # 6 Supervised Detector Failure
LED # 3 Telephone Line Failure LED # 7 Zone Inactivity Timeout
LED # 4
Radio Detector Battery Low
LED # 8
Dialler Kiss-off Failure
CURRENT SYSTEM ALARMS
