ENROLLING RADIO KEYS
-
P640E 1-20E
In the PW16 V6 we refer to wireless pendant transmitters as "Radio Keys". Because the PW16 recognises each
button as a separate function or user we refer to each button or user separately in that if you are loading a three
button radio key, you would actually be enrolling 3 separate radio users. It is possible to enrol several radio users
as one where you are able to program the transmitter code of the radio key (usually via dip switches) to key them
alike. Where you can not program the transmitter code of the radio keys you must enrol them as separate users.
To load a radio key whilst in installer program mode, for example radio key 1, press P640E1E. The keypad will
beep at 1 second intervals and the green learn mode LED on the Radio receiver board will flash on & off. Trigger
the transmitter you wish to enrol at this address (Radio key 1). The keypad will stop beeping and the receiver learn
LED will go out when the transmitters code has been stored. Repeat this sequence for all of the radio keys moving
through the addresses which correspond to the keys you require.
For example; P640E2E Radio Key #2
P640E3E Radio Key #3
P640E20E Radio Key #20
To delete a single radio key, repeat the learning process above but while in
learn mode press the “Enter” button ,while no transmitters are operating,
and this will remove any radio key code from that address.
RADIO KEYS OPTIOS A
RADIO KEY OPTIONS 1st Set
-
P661E - P680E
In the same way that permissions are set for user codes, Radio Keys are also assigned permissions which
determine their functionality.
P661E 1E Radio user #1 has Area "A" permissions (Default all)
2E Radio user #1 has Area "B" permissions
3E Radio user #1 has Area "C" permissions
4E Radio user #1 will arm
5E Radio user #1 will disarm
6E Radio user #1 can Arm Stay Mode on
7E Radio user #1 can Disarm Stay Mode off
8E Radio user #1 is disabled during alarm state
Option 1 Radio user #1 has Area "A" permissions
- The functions set by options 4-7 will be active in
Area "A"
Option 2 Radio user #1 has Area "B" permissions - The functions set by options 4-7 will be active in
Area "B"
Option 3 Radio user #1 has Area "C" permissions - The functions set by options 4-7 will be active in
Area "C"
Option 4 Radio user #1 will arm - When this option is enabled, radio user #1 will arm whichever area is
assigned by options 1-3
Option 5 Radio user #1 will disarm - When this option is enabled, radio user #1 will disarm whichever
area is assigned by options 1-3
Option 6 Radio user #1 can Arm Stay Mode
- When this option is enabled, radio user #1 will turn Stay
Mode on in whichever area is assigned by options 1-3
Option 7 Radio user #1 can Disarm Stay Mode
- When this option is enabled, radio user #1 will turn
Stay Mode off in whichever area is assigned by options 1-3
Option 8 Radio user #1 is disabled during alarm state - When this option is enabled, radio user #1 can
not be used to reset an alarm, i.e. it must be reset at the keypad.
Where P661E sets options for radio user #1, P662 sets options for radio user #2 etc
RADIO KEY TYPE
Pendant 1 Opt. B
1
2 3 4 5 6 7 8
