Page 49
At any stage, if you enter in an incorrect code you can press the “#” button on the remote telephone to clear all code
entries and then start again.
To end a Command Control session simply hang up the phone. The panel is monitoring the line at all times and 15
seconds after the last key press it will automatically hang up the line. This 15 second timer is active during the
whole command control process so a period of 15 seconds without a key press will cause the panel to hang-up.
LOCAL COMMAND CONTROL OF OUTPUTS
If a command control code for outputs is programmed (P371E) and the output/s are allowed to be locally controlled
(P201-P208, option 6) then entering the 4 digit code at a keypad will blank the display and the zone LED’s will now
indicate the output status e.g. if output 1 is on zone 1, led will be on. By now pressing the “1” button at the panel
keypad, output 1 can be turned off provided it is allowed to be locally controlled. To leave local command control
mode simply press the “Enter” button and the keypad will return to normal operation. If option 8 at addresses P301,
P401 or P501 are on, you can access this Local Command Control mode directly by simply pressing the “Control”
button at the keypad followed by the output number/s that are allowed to be controlled.
DIALLER PROGRAMMING
ENABLING DIALLER & SETTING DIALLING PARAMETERS - P370E
P370E 1-8E System Options (Default = 1,2,7) 1 = Enable dialler
2 = Fax defeat
3 = Disable line monitoring
4 =
DTMF or Pulse Dial
5 =
Normal or Reverse Pulse Dial
6 =
Spare
7 =
Auto-Detect Modem Format
8 = Force Bell103/V21
Option 1 Enable Dialler - This option is used to activate the dialler hardware. If this option is Off, all
dialler reporting activity will be disabled. - Default = Off
Option 2 Fax Defeat - This option enables fax defeat mode. When enabled the panel will look for
incoming rings between 1-4 rings (inclusive). If the
incoming call is then terminated the panel will answer
the next incoming call after one ring. If another call is
not established within 45 sec of the first call, the fax
defeat mode is reset. For fax defeat to work the auto
answer rings must be enabled by putting in a suitable
ring count (e.g. 25).
Option 3 Disable Line Monitoring -If this option is enabled, then the panel no longer tests the telephone
line.
Option 4
DTMF or Pulse Dial -
Selects DTMF or Pulse dialling. Led Off = DTMF Dial.
Option 5 Normal or Reverse Pulse Dial - With this option off,
the dialling pulses are normal i.e. a 1 = 1 pulse, a 9 = 9
pulses. If the option is on, then the pulses are reversed i .
e. a 1 = 9 pulses, a 9 = 1 pulse.
Option 6 Spare
Scenario #1
17
3
Max Dial for Scen
Prefix Number
