Crow PowerWave-16 - Pcb Wiring Instructions

Page 8
Outputs
Zn9 10 11 12 13 14 15 16
To
Key-
Pos
Neg
Clock
Data
Listen
0v 12v 1 2 3 4 5 6 7 Zn1 c 2 3 c 4 0v 12v 5 c 6 7 c 8 Tpr c Key 0v 12v
Line
Out
Line
In
AC
AC
GND
Keypad &
Communication
Port
Connection
To Telephone
Line
Listen-in to Output 1
PCB WIRING INSTRUCTIONS
Outputs
(Max Rating Each)
1&2 = 1.5Amps
*
Zone Inputs
Low Zn’s
= 1, 2, 3 & 4
High Zn’s
= 9, 10, 11 & 12
(Use Split EOL
Resistors For The
High Zones)
12Volt Regulated /
Filtered Power
Supply For
Detectors &
Accessories
Inputs
For
Keyswitch
& Siren /
Cabinet /
Junction
Box, Etc.
Zone Inputs
Low Zn’s
= 5, 6, 7 & 8
High Zn’s
=13, 14, 15 & 16
(Use Split EOL
Resistors For The
High Zones)
12Volt Regulated /
Filtered Power
Supply For
Detectors &
Accessories
12Volt Regulated /
Filtered Power
Supply For
Detectors &
Accessories
*
= AC Plug Pack / Battery Capacity & Fuse ratings Permitting
F1 F2 Batt
Serial
Port
1 2
Siren Driver Links
To Outputs 1 & 2
To
Phone
From
Line
Black - To Batt (-)
Red - To Batt (+)
From Line
Transformer
