Page 45
one where the data files were created and the panel receiving the files) must be the same
otherwise the panel will not work correctly.
DE-MAPPING OUTPUTS
P846E
1-8E DE-mapping Outputs 1-8 - This option is used to remove ALL default options assigned to any
output. This is a particularly useful tool when reassigning outputs to special functions such as
smoke detector reset, where you need to remove the standard defaults from an output. In
addition to removing all default programming this option will also make the reset time for the
selected output/s “0”.
RESET TO DEFAULTS
P840E - P848E
These addresses are used to reset sections of the programming back t o
defaults. Defaults are the factory settings. Most of the addresses b e l o w
default only one part of the programming. To reset the entire
configuration, including the event memory buffer you must use P845E.
P840E Reset user codes
P841E Reset dialler parameters
P842E Reset Radio parameters
P843E Reset PA & Voice board settings
P844E Reset the balance of the panel settings not included above
P845E Reset all panel parameters to default and clear the event memory buffer
P847E Clear event memory
P848E Reset PA board to clear all existing alarm messages
START EVENT PRINTING
P834E Start Event Printing - The alarm system stores the last 255 events in a printer buffer. These events
include time, date and an event description. To print the events, assuming the Serial Board is plugged
into the panel (with the link set to printer on the serial board) and connected to a printer with a RS232
input, a user with permission to print (e.g. P101-P150 option 4) enters client program mode (P-code-E,
program LED on solid), then enters P834E, the entire contents of the event buffer will be sent to the
printer.
WALK-TEST MODE
P836E
Walk-test mode - When in Installation or Client
Program mode, entering P836E will turn On walk-test mode. The k eypa d
Area B CMD Code
0
Area A status Msg
0
