Page 39
This address is where radio PIR's and other wireless detectors are enrolled into the PW16 and assigned to zones.
Assigning a zone as radio at addresses P444E & P464E will enable the zone as a wireless zone and disable the
hardwired zone input at the terminals on the control board.
To load a radio detector whilst in installer program mode, for example Zone 1, press P620E1E. The keypad will
beep at 1 second intervals and the green learn mode LED on the Radio receiver board will flash on & off. Trigger
the detector you wish to enrol at this address (Zone 1) The keypad will stop beeping and the receiver learn LED will
go out when the detectors code has been stored. Repeat this sequence for all of the radio detectors moving
through the addresses which correspond to the zones you require.
For example; P620E2E Radio Zone #2
P620E3E Radio Zone #3
P620E16E Radio Zone #16
To delete a single radio code, repeat the learning process above but while in learn mode press the “Enter” button ,
while no transmitters are operating, and this will remove any radio code from that address.
RADIO ZONE DETECTORS
OPTIONS
SET RADIO DETECTOR OPTIONS
-
P621E - P636E
This block of addresses is used to specify a specific type of radio detector. Special functions such as detector
tamper alarms, low battery indication and supervised signals can be selected based on the list below.
1 = Crow AE Series Battery low
2 = Crow AE Radio Reed Switch
3 = Crow Merlin PIR (Non-supervised)
4 = Crow Merlin PIR
(supervised signal active)
5 = Crow Merlin /
Checksum (supervised sig. active)
6
=
Crow Merlin /
Checksum (supervised sig.Ignored)
11 = Ness Devices battery Low
12 = Ness Radio Reed Switch
21 = Electronics Line Radio PIR
31 = Visonic K900 Radio PIR
Where P621E assigns options to the radio detector at zone 1, P622E assigns options to the radio detector at zone
2 etc.
P621E Radio detector zone 1 options P629E Radio detector zone 9 options
P622E Radio detector zone 2 options P630E Radio detector zone 10 options
P623E Radio detector zone 3 options P631E Radio detector zone 11 options
P624E Radio detector zone 4 options P632E Radio detector zone 12 options
P625E Radio detector zone 5 options P623E Radio detector zone 13 options
P626E Radio detector zone 6 options P634E Radio detector zone 14 options
P627E Radio detector zone 7 options P635E Radio detector zone 15 options
P628E Radio detector zone 8 options P636E Radio detector zone 16 options
ENROLLING RADIO KEYS
Enroll Pendants
1
Pendant 1 Opt. A
1 - - 4 5 - - -
