Output #6 reset time
- Default 0 (latching)
P557E 0-999E Output #7 reset time - Default 0 (latching)
P558E 0-999E Output #8 reset time - Default 0 (latching)
P559E 0-999E Mains Fail Dialler Report Delay - Default 600 seconds
P560E 0-999E Zone Alarm Report Delay to Dialler - Default 0 seconds
OUTPUT DELAY ON TIMES
-
P561E to P568E
P561E 0-999E
Output #1 delay on timer
- Default 0 (instant)
P562E 0-999E Output #2 delay on timer - Default 0 (instant)
P563E 0-999E Output #3 delay on timer - Default 0 (instant)
P564E 0-999E
Output #4 delay on timer
- Default 0 (instant)
P565E 0-999E Output #5 delay on timer - Default 0 (instant)
P566E 0-999E Output #6 delay on timer - Default 0 (instant)
P567E 0-999E Output #7 delay on timer - Default 0 (instant)
P568E 0-999E
Output #8 delay on timer
- Default 0 (instant)
P569E 0-999E Zone Inactivity Timer (0-999 hours) - Default 120 hours
SUPERVISED RADIO SIGNAL TIME
-
P570E
P570E 0-999E Supervised Radio Timer (0-999 minutes) - Default 240 minutes
OUTPUT PULSE TIMES
-
P571E to P578E
P571E 0-999E
Output #1 pulse time
-Default 0 (0 = Minimum 0.1
sec pulse) Times are in 1/10 second
P572E 0-999E Output #2 pulse time -Default 0 (0 = Minimum 0.1
sec pulse) increments
P573E 0-999E Output #3 pulse time -Default 0 (0 = Minimum 0.1
sec pulse)
P574E 0-999E Output #4 pulse time -Default 0 (0 = Minimum 0.1 sec pulse)
P575E 0-999E
Output #5 pulse time
-Default 0 (0 = Minimum 0.1 sec pulse)
P576E 0-999E Output #6 pulse time -Default 0 (0 = Minimum 0.1 sec pulse)
P577E 0-999E Output #7 pulse time -Default 0 (0 = Minimum 0.1 sec pulse)
P578E 0-999E Output #8 pulse time -Default 0 (0 = Minimum 0.1 sec pulse)
PW ACCESS CONTROL
The PW16 provides a basic Access Control function which utilises the keypad “Control” Function, one of the
outputs as a switching device and separate zone inputs as Request-to-
Exit and door position monitoring. Address P456E or P476E are used to
assign a zone to be the door position monitor input and address P457E
o r P477E are used to assign a zone as the request to exit input. Once
options have been programmed, a door which is fitted with a reed switch,
monitored by the zone as defined at P456E or P476E will cause a 24
hour alarm if it is opened without the Control Function being operated.
Once the control function has been operated with a valid code, a door
open too long (DOTL) timer is started and if the door is not closed again within the time determined by P537E (Area
"A"), P538E (Area "B:) or P539E (Area "C") a 24Hr alarm will be created. The control function to output mapping is
defined at addresses P291E through P298E for Area "A", P391E through P398E for Area "B" and P491E through
P498E for Area "C".
P537E 1-999E Area "A" door open too long time period - default 10 sec
P538E 1-999E Area "B" door open too long time period - default 10 sec
P539E 1-999E
Area "C" door open too long time period
- default 10 sec
PROGRAMMING RADIO DETECTORS
ENROLLING RADIO DETECTORS
-
P620E 1-16E
Enrol Radio Detect
2
Radio 1 Mode
0
