Page 43
of the week
P792E TZ1 Start Time P804E TZ5 Start Time
P793E TZ1 Finish Time P805E TZ5 Finish Time
P794E TZ2 Day of the week P806E TZ6 Day of the week
P795E TZ2 Start Time P807E TZ6 Start Time
P796E TZ2 Finish Time P808E TZ6 Finish Time
P797E TZ3 Day of the week P809E TZ7 Day of the week
P798E TZ3 Start Time P810E TZ7 Start Time
P799E TZ3 Finish Time P811E TZ7 Finish Time
P800E TZ4 Day of the week P812E TZ8 Day of the week
P801E TZ4 Start Time P813E TZ8 Start Time
P802E TZ4 Finish Time P814E TZ8 Finish Time
PROGRAMMING DAYLIGHT
SAVING
P817E - P822E
Given that your PW16 controller has a real time clock compliant with minutes
& hours of the day, days of the week and months of the year, it is only reasonable to assume automatic
adjustments for daylight saving. This block of addresses provides the PW16 with the information required to
perform the daylight saving adjustments as required.
P817E 0-5E Daylight Saving Start Sunday - This is the Sunday number in the month that daylight saving
will begin (values of 1-5 are allowed). Default = 1
P818E 0-12E Daylight Saving Start Month - This is month in which the above Sunday will occur. (Values of
1-12 are allowed). Default = 10
P819E 0-24E
Daylight Saving Start Hour
- This is the hour that daylight savings will begin (values of 0-24 are
allowed). Default = 2
P820E 0-5E
Daylight Saving End Sunday
- This is the Sunday
number in the month that daylight savings will end (values
of 1-5 are allowed). Default = 3
P821E 0-12E
Daylight Saving End Month
- This is the month in w h i c h
the Sunday number will occur (values of 1-12 are
allowed). Default = 3
P822E 0-24E Daylight Saving End Hour - This is the hour that daylight savings will end (values of 0-24 are
allowed. Default = 3
DYNAMIC DIAGNOSTIC DATA
P830E - P833E & P849E
These addresses are used to provide real time feedback from the p a n e l
as to the current status. These are intended as view only addresses a n d
only available in installer program mode.
P830E Misc System Flags - This address currently has o n l y
one option that shows the status of Daylight Saving.
If LED 8 is On then Daylight Saving is currently active.
8 = Daylight Saving active
P831E Display keyboard address - This option will cause the keypad you are operating to display it's
currently assigned address from 1-8. This feature is only available in installer program mode.
P832E Display partitions assigned to this keypad - This option will cause the keypad you are
operating to display it's currently assigned Areas. This feature is only available in installer
program mode.
Day of the week
2
Output Disable
Read from EE
2 3 4 5 6 7 8
- - - - - - - -
