Page 63
2 = “Arm” required before code
3 = “Stay” required before code
4 = Code required to arm
5 = Code required for control
6 = Control toggles
7 = Momentary control
8 = Control/Chime disables day zones
Partition “A” Misc Options
P302E
Misc partition options 2 - Default 3,4,6 1 = Key-switch enabled Page 28
2 = Use 2nd Key-switch
3 = Key-switch ARM's/STAY
4 = Pendant chirps when Armed
5 = Pendant chirps when in Stay Mode
6 = 2 sec pulse at set
7 = 2 sec pulse at unset
8 = Access control even when armed
P303E PARTITION "A" TIME AND DELAY OPTIONS-Default = 0 Page 26
1 = Set partition When Time Zone Ends
2 = Unset Partition When Time Zone Starts
3 = Disable Stay Mode Exit Delay
4 = Disable Set Mode Exit Delay
5 = Disable Stay Mode Entry Delay
6 = Disable Set Mode Entry Delay
7 = Use special Stay Mode entry timer
8 = Report Stay Mode alarms & Bypasses via dialler
Miscellaneous System Options “A”
P310E Options - Default 3,4,5,7 1 = Ignore Mains fail Page 30
2 = Siren Output on O/P # 1
3 = Siren Output on O/P # 2
4 = Turn Off Alert KP LED’s when armed
5 = Ignore Zone Tampers during exit delay
6 = Installer code direct access
7 = Installer lockout
8 = Area "C" is zones shared with Area A & B
Miscellaneous System Options “B”
P311E Options - Default 1 = System Tamper EOL or short circuit loop Page 30
2 = Key-switch Tamper EOL or short circuit loop
3 = Low Key-switch is momentary or latching
4 = High Key-switch is momentary or latching
5 =
6 =
7 =
8 =
**Keypad Listen-in Options**
P312E Keypad Listen-in Options P312E Options (Default = 1-7 On) Page 57
1 = Enabled During Dialling in Disarm State only
2 = Enabled During Dialling in Armed State only
3 = Enabled During Dialling in Monitor Mode State only
4 = Enabled Throughout the call in Disarm State only
5 = Enabled Throughout the call in Armed State only
6 = Enabled Throughout the call in Monitor Mode State only
7 = Listen-in Enabled when the panel answers a call
8 = Enabled at All Times
