Chapter 1 Introduction
1.3 Chassis Rear Description
The re he hot-swappable ar panel holds the chassis interface, the hot-swappable cooling fan modules, and t
8
power modul
1.4 Chassis Ph
Figure 1-3 Chassis Dimensions, in millimeters
es. The pluggable modules do not require any tools for removal and replacement.
Figure 1-2 Chassis Rear View
ysical Dimensions
Alarm Relay
Contacts
Cooling Fan
IEC AC Mains Input
Chassis Cascade
connectors
Terminal Strip
for DC Power
Power Module 1
AC Type Shown
Power Module 2
DC Type Shown
Cooling Fan
Protective
Earth Terminal
To Next Page
