Cub Cadet Ex450 User Manual

Ex Series Ex450
REF
NO.
PART NUMBER DESCRIPTION QTY
1 CY-1A7780-53200 HEADLIGHT ASSY, L.H. 1
2 CY-1A7000-53230 WIRE ASSY, LEAD 1
3 CY-198448-53320 BULB 12V45/45W 1
4 CY-1A7780-53250 LENS, SIDE L.H. 1
5 CY-1A7780-53260 LENS, SIDE R.H. 1
6 CY-1A7890-53270 LENS, CENTER 1
7 CY-1A7780-53300 HEADLIGHT ASSY, R.H. 1
8 CY-1A7000-53230 WIRE ASSY, LEAD 1
9 CY-198448-53320 BULB 12V45/45W 1
10 CY-1A7260-53350 SEAL, HEADLIGHT 2
11 CY-198153-53410 SPRING,ADJUST 6
12 CY-1A7260-61250 BRACKET ASSY, L 1
13 CY-1A7260-61260 BRACKET ASSY, R 1
14 CY-198071-61890 NUT 6,SPEED 4
15 CY-198475-65030 CUSHION 8
16 CY-198475-65030 CUSHION 6
17 CY-198071-65610 NUT M5,SPEED 8
18 CY-198071-65610 NUT M5,SPEED 3
19 CY-198071-65610 NUT M5,SPEED 4
20 CY-26557-060352 SCREW 6
143
FIG. 82. FRONT LAMP
Copyright 2008 Cub Cadet Yanmar LLC
