Cub Cadet Ex450 User Manual

Ex Series Ex450
REF
NO.
PART NUMBER DESCRIPTION QTY
1 CY-194990-22150 NUT W/WASHER 10 1
2 CY-198253-27510 KNOB 1
3 CY-198071274701 HOLDER 1
4 CY-198149-27490 SHAFT, FORK 1
5 CY-198253275201 LEVER, RANGE SHIFT 1
6 CY-198149-27530 PLUG M12 1
7 CY-194680-27540 SPRING, FORK LOCK 1
8 CY-198149-27560 ARM, SHIFT 1
9 CY-198149-27570 FORK, SHIFT 2
10 CY-22217-080000 WASHER, 8 1
11 CY-22242-000170 CIRCLIP 17 1
12 CY-22351-035032 SPRING PIN 3.5X32 1
13 CY-22351-060032 SPRING PIN 6X32 2
14 CY-22351-060032 SPRING PIN 6X32 1
15 CY-23414-120016 GASKET 12 1
16 CY-24190-080001 BALL 1/4, STEEL 1
17 CY-24311-000160 O-RING 1A P-16.0 2
18 CY-24321-000250 O-RING 1A G-25.0 1
19 CY-26218-080252 STUD,BOLT 1
20 CY-26716-080002 NUT M 8 1
100
FIG. 50. SUB CHANGE LEVER
Copyright 2008 Cub Cadet Yanmar LLC
