Cub Cadet Ex450

Ex Series Ex450
REF
NO.
PART NUMBER DESCRIPTION QTY
1 CY-198133-24361 PLATE, CENTER 1
2 CY-198133-25310 RETAINER 1
3 CY-22252-000470 CIRCLIP 47(H) 1
4 CY-22252-000620 CIRCLIP 62(H) 1
5 CY-22252-000800 CIRCLIP 80 1
6 CY-22312-100200 PARALLEL PIN 10X20 4
7 CY-26013-100552 BOLT M10X 55 2
8 CY-26013-100852 BOLT W/WASHER 10X 85 1
9 CY-26013-101502 BOLT,SPRING 10X150 1
82
FIG. 35. CENTER PLATE
Copyright 2008 Cub Cadet Yanmar LLC
