Cub Cadet Ex450

Ex Series Ex450
REF
NO.
PART NUMBER DESCRIPTION QTY
1 CY-198251-13270 SPACER 30X45X 2 1
2 CY-198241-13280 SPACER 33X40X15.5 1
3 CY-198137-13300 PROPELLER SHAFT 1
4 CY-198133-13340 COUPLING 1
5 CY-198137-13350 SHAFT, PROPELLER 1
6 CY-194274-13350 BOOT, RUBBER 2
7 CY-194321-13360 WASHER 2
8 CY-198441-13370 SPRING,RETAINER 1
9 CY-194321-13380 SEAL, SPLINE SHAFT 1
10 CY-22417-400500 COTTER PIN 4.0X50 1
11 CY-24190-110001 BALL 11/32, STEEL 12
57
FIG. 16. PROPELLER SHAFT
Copyright 2008 Cub Cadet Yanmar LLC
