Cub Cadet Ex450

Ex Series Ex450
REF
NO.
PART NUMBER DESCRIPTION QTY
1 CY-1A8170-34300 R1 TIRE KIT,WHEEL L 1
2 CY-1A8170-34310 TIRE, R1 14.9X24 1
3 CY-1A8170-34330 WHEEL, R1 R 1
4 CY-1A8170-34340 RIM ASSY, R1 1
5 CY-1A8170-34360 DISC ASSY, R1 1
6 CY-1A8170-34370 BOLT, R1 6
7 CY-1A8170-34380 NUT, R1 6
8 CY-1A8170-34390 WASHER, R1 6
9 CY-1A8170-34400 TIRE KIT, R1 REAR R 1
10 CY-1A8170-34310 TIRE, R1 14.9X24 1
11 CY-1A8170-34330 WHEEL, R1 R 1
12 CY-1A8170-34340 RIM ASSY, R1 1
13 CY-1A8170-34360 DISC ASSY, R1 1
14 CY-1A8170-34370 BOLT, R1 6
15 CY-1A8170-34380 NUT, R1 6
16 CY-1A8170-34390 WASHER, R1 6
17 CY-1A8170-14210 BOLT, HUB M14 16
110
FIG. 59. REAR WHEEL TIRE 1
Copyright 2008 Cub Cadet Yanmar LLC
