Cub Cadet Ex450

Ex Series Ex450
REF
NO.
PART NUMBER DESCRIPTION QTY
1 CY-194274-22090 SEAL COLLAR 35X40X17 1
2 CY-198133-25210 SHAFT, MAIN 1
3 CY-198240-25220 GEAR, MAIN 1
4 CY-198133-25230 MAIN GEAR 27 1
5 CY-198133-25240 GEAR, MAIN 1
6 CY-198133-25270 CASE, SEAL 1
7 CY-194250-25520 SPACER 35X45X2 1
8 CY-22242-000340 CIRCLIP 34 4
9 CY-22242-000450 CIRCLIP 45 1
10 CY-22252-000420 CIRCLIP 42 1
11 CY-24101-060044 BALL BEARING #6004 1
12 CY-24101-060074 BALL BEARING 1
13 CY-24101-060094 BALL BEARING 1
14 CY-24164-000352 CIRCLIP 35 2
15 CY-24421-223508 SEAL TC22 35 08, OIL 1
85
FIG. 38. MAIN SHAFT
Copyright 2008 Cub Cadet Yanmar LLC
