Ex Series Ex450
REF
NO.
PART NUMBER DESCRIPTION QTY
1 CY-198390-25790 BEARING 6307R SH2 1
2 CY-198149-31400 GEAR W/COUNTERSHAFT 1
3 CY-194066-13130 BOLT M10X 25 6
4 CY-198320-31530 WASHER, DIFFERENTIAL 2
5 CY-198320-31550 GEAR, DIFFERENTIAL 1
6 CY-194320-31560 GEAR, DIFFERENTIAL 1
7 CY-198320-31570 PINION, DIFFERENTIAL 2
8 CY-198320-31630 WASHER, DIFFERENTIAL 2
9 CY-198320-31820 SHAFT, DIFFERENTIAL 1
10 CY-198320-32111 HOUSING, DIFF. 1
11 CY-22217-100000 SPRING WASHER 10 6
12 CY-22242-000500 CIRCLIP 50 1
13 CY-22351-060050 SPRING PIN 6X50 1
14 CY-24101-060104 BALL BEARING 1
15 CY-24101-062114 BALL BEARING 1
16 CY-794251-13910 SHIM SET 1
17 CY-198250-32310 CARRIER,DIFFERENTIAL 1
18 CY-26013-080252 BOLT M 8X 25 7
104
FIG. 54. RING GEAR
Copyright 2008 Cub Cadet Yanmar LLC
