Cub Cadet Ex450 User Manual

Ex Series Ex450
REF
NO.
PART NUMBER DESCRIPTION QTY
1 CY-198212326111 HOUSING, REAR 2
2 CY-194180-32640 PLATE, PUSH 3
3 CY-198240-32640 PACKING, REAR AXLE 2
4 CY-194640326501 COVER, OIL SEAL 2
5 CY-198320-32660 GASKET 2
6 CY-194327-32730 SEAL TC6Y 7510014.5 2
7 CY-22217-100000 SPRING WASHER 10 2
8 CY-22312-100180 PARALLEL PIN 10X 18 4
9 CY-22635-600120 RIVET 3
10 CY-26013-100302 BOLT M10X 30 8
11 CY-26013-120402 BOLT M12X 40 16
12 CY-26013-120502 BOLT M12X 50 4
13 CY-26116-100852 BOLT M10X 85 PLATED 2
105
FIG. 55. REAR HOUSING
Copyright 2008 Cub Cadet Yanmar LLC
