Ex Series Ex450
REF
NO.
PART NUMBER DESCRIPTION QTY
1 CY-198200-18350 KNOB;REVERSER LEVER 1
2 CY-198133-27350 BOOT 1
3 CY-198133-27900 ROD COMP.,REVERSER 1
4 CY-194990-20170 NUT W/WASHER 8 1
5 CY-194170-27180 ROD,END (R) 1
6 CY-194820-27370 END (L), ROD 1
7 CY-198133-27910 SPEED CHANGE ROD 1
8 CY-26716-080002 NUT M 8 1
9 CY-22137-100000 WASHER 10,POLISHED 1
10 CY-22217-080000 WASHER, 8 1
11 CY-22272-000120 CIRCLIP E-12 1
12 CY-26116-080252 BOLT M 8X 25 PLATED 1
13 CY-26346-080002 U-NUT M 8 PLATED 1
14 CY-26756-100002 LOCK NUT M10 PLATED 1
15 CY-1A778027160 HOLDER, REVERSER ARM 1
16 CY-1A778027210 ARM, LINK REVERSER 1
17 CY-24104-060014 BALL BEARING 6001UU 1
18 CY-24104-060034 BALL BEARING 1
19 CY-26013-080252 BOLT M 8X 25 2
99
FIG. 49. REVERSE LEVER
Copyright 2008 Cub Cadet Yanmar LLC
