Ex Series Ex450
REF
NO.
PART NUMBER DESCRIPTION QTY
1 CY-1A7780222511 SHAFT,CLUTCH RELEASE 1
2 CY-198149-22280 YOKE, CLUTCH SHIFT 1
3 CY-198071-22320 BOLT M8X40 2
4 CY-198240-22200 SLEEVE ASSY, BEARING 1
5 CY-194274-22160 BUSH 35X42X32 2
6 CY-194274-22170 FELT 2
7 CY-198240-22220 SLEEVE, BEARING 1
8 CY-194274-22290 BEARING, CLUTCH 1
9 CY-198327-22230 SPRING,RETURN 2
78
FIG. 33. CLUTCH RELEASE
Copyright 2008 Cub Cadet Yanmar LLC
