Cub Cadet Ex450

Ex Series Ex450
REF
NO.
PART NUMBER DESCRIPTION QTY
1 CY-198129-05190 NUT, PUSH 6 24
2 CY-1A7260-60640 URETHANE, A COVER 2
3 CY-1A7260-60670 URETHANE, B COVER 2
4 CY-1A7270-60750 WEATHER-STRIP, 440 2
5 CY-1A7260-60900 URETHANE, C COVER 2
6 CY-1A7780610201 COVER ASSY, SIDE L.H 1
7 CY-1A7780610301 COVER ASSY,SIDE R.H. 1
8 CY-1A7260610601 NET, L SIDE COVER 1
9 CY-1A7260610701 NET, R SIDE COVER 1
10 CY-198220-61351 LOCK COMP.,CAM 4
11 CY-1A7260-61400 STAY, R SIDE COVER 2
12 CY-1A7260-61450 STAY, F SIDE COVER L 1
13 CY-1A7260-61460 STAY, F SIDE COVER R 1
14 CY-198220-61800 RUBBER, CUSHION 4
15 CY-26106-080102 BOLT M 8X 10 PLATED 8
155
FIG. 89. SIDE COVER
