Ex Series Ex450
REF
NO.
PART NUMBER DESCRIPTION QTY
1 CY-198251134501 RETAINER, BEARING 1
2 CY-198251136001 AXLE HOUSING RH.ASSY 1
3 CY-198251-11220 BUSH 35X41X40 2
4 CY-194321-11940 SEAL VB 354105, OIL 2
5 CY-198251136101 HOUSING, FRONT AXLE 1
6 CY-794321-13660 SHIM SET 1
7 CY-194641-13670 SHIM SET, PINION 1
8 CY-23491-140002 PLUG 14 1
9 CY-24311-000160 O-RING 1A P-16.0 1
10 CY-24321-000700 O-RING 1A G70.0,NBR 1
11 CY-24321-001000 O-RING 1A G-100.0 2
12 CY-24321-001700 O-RING 1A G-170.0 1
13 CY-24421-456209 SEAL TC 456209, OIL 1
14 CY-26013-120302 BOLT W/WASHER M12X30 11
15 CY-26013-120302 BOLT W/WASHER M12X30 16
16 CY-26450-080252 BOLT M 8X 25 8
59
FIG. 18. FRONT AXLE HOUSING
Copyright 2008 Cub Cadet Yanmar LLC
