Ex Series Ex450
REF
NO.
PART NUMBER DESCRIPTION QTY
1 CY-198251118001 ARM L COMP.,KNUCKLE 1
2 CY-23876-040000 PLUG PT 1/2 1
3 CY-198251118201 KNUCKLE ARM R CMP 1
4 CY-198251-13630 GAUGE,OIL LEVEL 1
5 CY-24311-000180 O-RING 1A P-18.0 1
6 CY-22217-120000 SPRING WASHER 12 4
7 CY-22312-100180 PARALLEL PIN 10X 18 4
8 CY-26013-120802 BOLT W/WASHER12*80 4
9 CY-26216-120352 STUD M12X 35 PLATED 4
10 CY-26716-120002 NUT 12 4
53
FIG. 12. KNUCKLE ARM
Copyright 2008 Cub Cadet Yanmar LLC
