Cub Cadet Ex450

Ex Series Ex450
REF
NO.
PART NUMBER DESCRIPTION QTY
1 CY-1A7780-21400 DUAL CLUTCH ASSY 1
2 CY-1A7780-21410 CLATCH DISK PTO 1
3 CY-1A7780-21420 DISC, TRACTI CLUTCH 1
4 CY-194274-21510 PARALLEL PIN 3
5 CY-194274-21520 PARALLEL PIN 3
6 CY-194274-21530 WASHER 3
7 CY-194274-21550 PIN, KNOCK 4
8 CY-194274-21610 ROD ASSY, RELEASE 3
9 CY-194278-21640 SPRING, DIAPHRAGM 2
10 CY-194274-21650 BOLT 3
11 CY-194274-21660 NUT 3
12 CY-194278-21670 BOLT 3
13 CY-194274-21680 PIN 3
14 CY-194274-21690 NUT M10 3
15 CY-194278-21710 PLATE A,PRESSURE 1
16 CY-198325-21720 PLATE B,PRESSURE 1
17 CY-198325-21730 COVER A,CLUTCH 1
18 CY-198327-21740 COVER B,CLUTCH 1
19 CY-194274-21750 LEVER W/BUSH 3
20 CY-22417-160150 COTTER PIN 1.6X15 3
21 CY-22137-080000 WASHER 8, POLISHED 2
22 CY-26106-080802 BOLT M 8X 80 PLATED 6
23 CY-198133-22121 SHAFT,MAIN DRIVE,IN. 1
77
FIG. 32. DUAL CLUTCH & SHAFT
Copyright 2008 Cub Cadet Yanmar LLC
