REF

NO.

PART NUMBER DESCRIPTION QTY

1 CY-198129-27281 CAM ROLLER 1

2 CY-1A8160-29040 ROD, HYDRAULIC 1

3 CY-1A8160-35080 HEAD, PEDAL 2

4 CY-1A8160-35100

PEDAL, HST KIT INCLUDES REF. NO.

5 THROUGH 21.

5 CY-1A8160-35110 HST PEDAL, F CMP 1

6 CY-1A8160-35210 HST PEDAL, R CMP 1

7 CY-1A8160-35240 BRACKET ASSY, HST PED 1

8 CY-1A8160-35310 F PEDAL SHAFT CMP 1

9 CY-198167-35311 PLATE, KEEP 2

10 CY-1A8160-35360 R PEDAL SHAFT CMP 1

11 CY-198167-35411 SPRING, REVERSE PEDAL 1

12 CY-22137-120000 WASHER 12, POLISHED 2

13 CY-22242-000120 CIRCLIP 12 1

14 CY-22351-035036 SPRING PIN 3.5X36 2

15 CY-22351-060036 SPRING PIN 6X36 2

16 CY-24104-060024 BALL BEARING 6002UU 4

17 CY-24104-062014 BALL BEARING 6201UU 1

18 CY-26106-080122 BOLT M 8X 12 PLATED 2

19 CY-26106-080202 BOLT M 8X 20 PLATED 1

20 CY-26106-080252 BOLT M 8X 25 PLATED 1

21 CY-26716-080002 NUT M 8 2

22 CY-1C6281-52320 PIN 8, SNAP 1

23 CY-22417-200300 COTTER PIN 2.0X30 1

24 CY-22137-080000 WASHER 8, POLISHED 1

25 CY-22137-100000 WASHER 10, POLISHED 1

26 CY-22487-080160 PIN 8X 16 1

27 CY-22487-100280 PIN, 10 X 28 1

28 CY-26106-080202 BOLT M 8X 20 PLATED 3

FIG. 65. HYDRAULIC PEDAL
