Cub Cadet Yanmar Ex32002 User Manual

Ex Series Ex3200
REF
NO.
PART NUMBER DESCRIPTION QTY
REF
NO.
PART NUMBER DESCRIPTION QTY
1 CY-194990-22130 NUT W/WASHER 6 1 28 CY-194250-51650 CLAMP 66 4
2 CY-194990-22140
NUT W/WASHER 8 - S/N
F000155 & BELOW
1 29 CY-194680-51670 BAND 2
2 CY-194990-22050
NUT W/WASHER 8 - S/N
F000156 & ABOVE
1 30 CY-194680-51670 BAND 1
3 CY-1A8160-51100
WIRING HARNESS A
CMP
1 31 CY-1A7260-51710 GROMMET, CABLE 1
4 CY-1A7500-51130 DIODE, 3.0A 1 32 CY-1A7260-52510 STAY, FUSE BOX 1
5 CY-1A8160-51130 DIODE, 3.0AX2 1 33 CY-124550-77030 COVER, TERMINAL 1
6 CY-1A7500-51160 CLIP, HARNESS 2 34 CY-198291-77870
COVER, HOSE
PROTECTOR
2
7 CY-194275-51160 COUPLER 1 35 CY-198291-77870
COVER, HOSE
PROTECTOR
1
8 CY-194275-51170 PLUG 1 36 CY-198291-77870
COVER, HOSE
PROTECTOR
1
9 CY-198535-52110 FUSE 4 37 CY-198291-77870
COVER, HOSE
PROTECTOR
1
10 CY-198535-52120 FUSE 10A 4 38 CY-1E6102-83230
CLAMP, BATTERY
CABLE
1
11 CY-198535-52130 FUSE 15A 2 39 CY-194440-51620
CLAMP, WIRE
HARNESS
1
12 CY-1A7260-52410 COVER, FUSE BOX 1 40 CY-26106-060122 BOLT M 6X 12 PLATED 2
13 CY-1A8160-65440 LABEL, FUSE 1 41 CY-26106-060162 BOLT M 6X 16 PLATED 4
14 CY-1A7330-51130 HARNESS C ASSY. 2 42 CY-26106-080122 BOLT M 8X 12 PLATED 4
15 CY-1A8160-51180
WIRING HARNESS,
START
1 43 CY-1C6560-06300 BOLT M8X16, EARTH 1
16 CY-198153-51700 FUSE, 80A SLOW BLOW 2 44 CY-26106-080122 BOLT M 8X 12 PLATED 1
17 CY-1A8160-51200
WIRING HARNESS B
CMP
1 45 CY-26106-080122 BOLT M 8X 12 PLATED 1
18 CY-1A7500-51130 DIODE, 3.0A 1 46 CY-26106-080122 BOLT M 8X 12 PLATED 1
19 CY-198220-51170 WIRE 1 47 CY-26106-080122 BOLT M 8X 12 PLATED 2
20 CY-194170-51210 GROMMET, 25 2 48 CY-26106-080302 BOLT M 8X 30 PLATED 1
21 CY-198220-51250
CLAMP - S/N F000155 &
BELOW
1 49 CY-29622-140001 BAND 140 1
21 CY-194440-51620
CLAMP - S/N F000156 &
ABOVE
1 50 CY-29622-140001 BAND 140 2
22 CY-1A8160-51310 WIRING HARNESS, 1 51 CY-29622-140001 BAND 140 2
23 CY-198253-51410 CABLE 1 52 CY-29622-140001 BAND 140 4
24 CY-1A8160-51420 CABLE, BATTERY,NEG 1 53 CY-29622-250001 BAND RF 250 1
25 CY-194440-51620
CLAMP, WIRE HARNESS
2 54 CY-29622-250001 BAND RF 250
1
26 CY-194440-51620 CLAMP, WIRE HARNESS 4 55 CY-198291-77870
COVER, HOSE
PROTECTOR
1
27 CY-194680-51670 BAND 1 56 CY-194990-22140 NUT W/WASHER 8 1
FIG. 82. WIRE HARNESS
127
