Ex Series Ex3200
REF
NO.
PART NUMBER DESCRIPTION QTY
1 CY-1A8160-17460 BRACKET (PIPE CLAMP) 1
1-1 CY-1A8160-17461 BRACKET (PIPE CLAMP) - S/N F000155 & BELOW 1
2 CY-1A8160-17700 LINE, PST L.H. 1
3 CY-1A8160-17720 LINE, PST PUMP 1
4 CY-1A8160-17740 LINE, PST TANK 1
5 CY-1A8160-17780 LINE, PST R.H. 1
6 CY-198268-17790 CLAMP, PIPE 12 - S/N F000155 & BELOW 1
7 CY-198230-17850 HOSE 2
8 CY-1A8160-17950 BAR, CLAMP 1
9 CY-194990-22130 NUT W/WASHER 6 1
10 CY-198220-46560 CLAMP COMP - S/N F000155 & BELOW 1
11 CY-198245-46680 BOLT 3/4-16 1
12 CY-198245-46680 BOLT 3/4-16 1
13 CY-198245-46680 BOLT 3/4-16 1
14 CY-198245-46680 BOLT 3/4-16 1
15 CY-198220-48140 FLANGE 1
16 CY-23414-190000 PACKING -19 2
17 CY-23414-190000 PACKING -19 2
18 CY-23414-190000 PACKING -19 2
19 CY-23414-190000 PACKING -19 2
20 CY-24311-000200 O-RING 1A P-20.0 1
21 CY-24311-000200 O-RING 1A P-20.0 1
22 CY-26018-060352 BOLT M 6X 35 4
23 CY-26106-060202 BOLT M 6X 20 PLATED 1
24 CY-26106-060402 BOLT M 6X 40 PLATED 2
25 CY-26106-080122 BOLT M 8X 12 PLATED 2
26 CY-26106-080352 BOLT M 8X 35 PLATED - S/N F000155 & BELOW 1
27 CY-26106-060122 BOLT M 6X 12 PLATED 1
28 CY-1E6102-84970 BAND 140, WIRE LOCK 1
29 CY-1A8160-17440 BRACKET, CLAMP KIT - S/N F000156 & ABOVE 1
30 CY-1A8160-17450 BRACKET COMP - S/N F000156 & ABOVE 1
31 CY-1A8160-17461 BRACKET (PIPE CLAMP) - S/N F000156 & ABOVE 1
32 CY-195616-24930 TRIM - S/N F000156 & ABOVE 1
33 CY-198268-17790 CLAMP, PIPE 12 - S/N F000156 & ABOVE 2
34 CY-26106-080252 BOLT M 8X 25 PLATED - S/N F000156 & ABOVE 2
61
FIG. 28. POWER STEERING LINES
Copyright 2007 Cub Cadet Yanmar LLC
