Ex Series Ex3200

REF

NO.

PART NUMBER DESCRIPTION QTY

1 CY-1A8160-13930 NUT 10 2

2 CY-194855-24020 SEALANT, TUBE 1

3 CY-1A8160-24100 CASE, MISSION CMP 1

4 CY-26216-100252 STUD M10X 25 PLATED 1

5 CY-26216-100252 STUD M10X 25 PLATED 2

6 CY-198220-24211 COVER, MISSION CASE 1

7 CY-198220-24341 COVER, REAR COMP. 1

8 CY-119860-34810 GUIDE, DIPSTICK 1

9 CY-198220-24360 GASKET, REAR COVER 1

10 CY-1A8160-24390 BOLT, 10X75 2

11 CY-198220-24480 COVER, BOTTOM 1

12 CY-1A8160-24920 FLANGE, STRAINER 1

13 CY-194850-24960 GAUGE COMP, OIL 1

14 CY-194180-26690 O-RING 2035 1

15 CY-198266-28390 BOLT, 10X35 4

16 CY-194440-51620 CLAMP, WIRE HARNESS 1

17 CY-22217-100000 SPRING WASHER 10 1

18 CY-22217-100000 SPRING WASHER 10 2

19 CY-22312-080160 PARALLEL PIN 8X 16 2

20 CY-22312-100180 PARALLEL PIN 10X 18 4

21 CY-24321-000950 O-RING 1A G-95.0 1

22 CY-24421-405508 SEAL TC40 55 08, OIL 1

23 CY-26013-080202 BOLT W/WASHER M8X20 2

24 CY-26013-080202 BOLT W/WASHER M8X20 7

25 CY-26013-100302 BOLT M10X 30 3

26 CY-26013-080352 BOLT M 8X 35 10

27 CY-26716-100002 NUT 10 1

28 CY-26716-100002 NUT 10 2

29 CY-27260-200000 PLUG 20, BORE 1

FIG. 36. TRANSMISSION CASE
