REF

NO.

PART NUMBER DESCRIPTION QTY

1 CY-198280-24340 COLLAR, 12X16X17 2

2 CY-1A8160-27200 ARM, TRUNNION CMP 1

3 CY-1A8160-29540 COLLAR, TRUNNION 1

4 CY-1A8160-29550 PIN,TRUNNION 1

5 CY-1A8160-29560 ROD END ASSY, HST 1

6 CY-198280-29570 ROD END 1

7 CY-1A8160-29580 BOLT,ROD END 1

8 CY-1E8080-64710 ROD END 1

9 CY-26716-120002 NUT 12 2

10 CY-22137-080000 WASHER 8, POLISHED 1

11 CY-22217-120000 SPRING WASHER 12 1

12 CY-24311-000160 O-RING 1A P-16.0 2

13 CY-24321-000600 O-RING 1A G-60.0 1

14 CY-26106-080552 BOLT M 8X 55 PLATED 1

15 CY-26106-120552 BOLT, 12 X 55 3

16 CY-26346-080002 U-NUT M 8 PLATED 1

17 CY-26366-080002 NUT M 8 1

18 CY-26716-120002 NUT 12 1

19 CY-1A8160-25150 HST UNIT 1

20 CY-1A6750-29850 PLUG 5

21 CY-158802-85421 OIL SEAL 2

22 CY-158805-85420 SEAL 25*45*8.OIL 1

23 CY-158830-85960 PLUG 1

24 CY-168HJ1-85500 NCR, VALVE+0.7 2

25 CY-168HJ1-85580 PLUG 2

26 CY-168HP1-85570 SPRING (CHECK VALVE) 2

27 CY-168HJ1-85490 O RING S58.2 1

28 CY-22252-000360 CIRCLIP 36 2

29 CY-24315-000140 O-RING 1B P-14.0 5

30 CY-24315-000180 O-RING 1B P-18.0 3

31 CY-26450-080202 BOLT M 8X 20 4

FIG. 52. HYDROSTATIC (HST)
