Fuses and bulbs
●
P
oint a lamp at the fuse t
o see if it has
blown.
To replace a fuse
●
Remove the fuse.
●
Replace the blown fuse by one with an
identical amperage rating (same colour and
markings) and identical size.
●
Replace the cover again or close the fuse
box lid.
Fuse placement
Only replace fuses with a fuse of the same
amper
ag
e (same colour and markings) and
size.
Fuses in the vehicle interior
No. Consumers/Amps
4 Alarm horn 7.5
5 Gateway 7.5
6 Automatic gearbox lever 7.5
7
Air conditioning and heating
control panel, back window
heating, auxiliary heating.
10
8
Diagnosis, electronic parking
brake switch, light switch, reverse
light, interior lighting, driving
mode, lit-up door sill
7.5
No. Consumers/Amps
9 Steering column 7.5
10 Radio display 7.5
11 Left lights 40
12 Radio 20
14 Air conditioner fan 40
15 Steering column release 10
16 Connectivity Box 7.5
17 Instrument panel, OCU 7.5
18 Rear camera 7.5
19 Kessy 7.5
20 SCR, engine relay, 1.5 10/15
21 4x4 Haldex Control Unit 15
22 Trailer 15
23 Electric sunroof 30
24 Right lights 40
25 Left door 30
26 Heated seats 30
27 Interior light 30
28 Trailer 25
31 Rear lid control unit 30
No. Consumers/Amps
32
Control unit for parking aid, front
camera and radar
7.5/10
33 Airbag 7.5
34
Reverse switch, climate sensor,
electrochromic mirror, rear pow-
er sockets (USB)
7.5
35
Diagnosis, headlight control unit,
headlight adjuster
7.5
36 Right LED headlight 7.5
37 Left LED headlight 7.5
38 Trailer 25
39 Right door 30
40 12V socket 20
42 Central locking 40
43 Beats Audio CAN and MOST. 30
44 Trailer 15
45 Electric driver's seat 15
47 Rear window wiper 15
49 Starter motor; clutch sensor 7.5
52 Driving mode. 15
53 Heated rear window 30
»
