CYBEX Arc Trainer 772A User Manual

4. Remove the left inner rear cover and two screws using a Phillips screwdriver.
QtyDescriptionItem
1Left inner rear cover1
2Screws2
5. Repeat steps 1 through 4 for the right side.
Remove rear arm handle linkage
1. Remove screw and flat washer from arm handle linkage and front foot plate arm using a 3/16” Allen
wrench.
Qty.DescriptionItem
1Arm handle linkage1
1Front foot plate arm2
1Flat washer3
1Screw4
2. Remove arm handle linkage from front foot plate arm.
Page 109 of 202
Cybex 772A, 772AT Arc Trainer Part Number
