3. Unplug optional iPod cable.
The iPod cable is held in place by a notch in the access cover.
a) Press in both side latches of cable connector.
b) Ensure latches disengage from the connector.
c) Unplug cable by holding down latches on both sides and pulling straight out from connector.
Do not pull on wires, remove by connector.
Remove MCC board
Remove four screws securing MCC board to console assembly using a Phillips screwdriver.
Qty.DescriptionItem
1Console assembly1
1MCC board2
4Screw3
Install MCC board
Install the four screws securing the MCC Board to the console assembly using a Phillips screwdriver.
Page 167 of 202
Cybex 772A, 772AT Arc Trainer Part Number
