CYBEX Arc Trainer 772A User Manual

2. Unplug cables from MCC board by un-latching connectors with the following procedure:
a) Press in the top of the cable connector.
Qty.DescriptionItem
1
DO NOT PULL CONNEC-
TOR OUT BY THE WIRES!
1
1Step a, Latch2
1Step b3
1Step c4
b) Ensure latch disengages the connector.
c) Unplug cable by holding down latch and pulling straight out from connector. Do not pull on wires,
remove by connector.
3. Unplug optional iPod cable.
The iPod cable is held in place by a notch in the access cover.
a) Press in both side latches of cable connector.
b) Ensure latches disengage from the connector.
c) Unplug cable by holding down latches on both sides and pulling straight out from connector.
Do not pull on wires, remove by connector.
Page 172 of 202
Cybex 772A, 772AT Arc Trainer Part Number
